RT-1306 Thermal Stability Testing Machine
Product Details：
Equipment summary
RT-1306 Thermal Stability Testing machine applies to test wire and cable, the soft PVC, plastic insulating sheath at 200 Degree ± 0.5 Degree heat stability temperature, its structure and performance are met GB/T2951.7-1997 standards.
Corresponding standard
According with GB/T2951.7,IEC60811-3-2:2008 and GB/T8815-2002 and GB/T2951-32:2008
Technical parameters
Model: RT-1306
Power supply voltage: 220V (AC)
Glass tube diameter: 6mm
Temperature range: room temperature -250 Degree
Temperature deviation: ± 0.5 Degree
Tank Capacity: 3000ml
Heater power: 1.25kw
Test Strips:1pcs specimen paper PH value of 1 to 10
Timer: 0.01 ~ 99.99S/M/H continuously adjustable
Glass tube: inner diameter 4mm, outer diameter 5mm, length 110mm, closed at one end (a total of 10)
