Equipment summary:
RT-611 Safety shoes impact resistance tester in line with ” national standard “, steel head of safety shoes placed in the bottom of machines red-edge, heavy hammer at a certain height free fall to impact, then check the degree of subsidence, the weight of heavy hammer is 23 ± 0.2kg . The sample fixed on the device, adjust the height of heavy hammer. Then make heavy hammer free-fall to impact test. After the test, remove the rubber to measure its size, the value ≥ 15mm is OK.
Corresponding standard:
CNS6863, CSA, ANSI, EN344, QAS
Technical parameters:
Model | RT-611 Safety shoes impact resistance tester |
Hammer | (20±0.2)KG (EN,GB) or (22±0.2) KG (CSA,USA standard) |
Impact blade | (EN)3±0.1mm(R),(ANSI)ø25.4mm |
Impact energy | (EN) 200J, (ANSI) 100±2J |
horsepower | DC1/4HP |
Height of fall | 0~1100mm |
Volume | 75×85×181cm |
weight | 190KG |
