RT-833 Nonwoven Softness Tester

Category 6. Textile Testing Machine

Additional information

RT-833 Paper/non-woven/Film Fabrics Softness Tester

It is suitable for the determination of all kinds of toilet paper, tissue paper and other toilet materials with requirements for softness.

Product Details：

Application

It is used for the softness measurement of sheet-like soft software materials such as medium and high grade toilet paper, tobacco sheets and fabrics.

Standards compliant

GB/T 8942 Determination of paper softness, ASTM D2923 polyolefin film and sheet stiffness test method

TAPPI T498, INDA IST 90.3, EDANA WSP 90.3

Features

1, The instrument measuring device adopts the principle of leverage to reduce data fluctuation caused by vibration.

2, The transmission device is stable, precise and accurate, using stepper motor, streamlined and reliable.

3, High-definition color touch screen display, easy to operate.

4, High-precision load cell, the test results are more accurate.

5, The test process displays real-time force values and graphs for easy observation.

6, Equipped with a micro thermal printer, can analyze and count the results of each group of data, low noise, clear font.

Technical Parameters

Measurement range:	(10~1000) mN
Precision:	0.1mN
The total stroke of the probe:	12mm, can be set
The probe penetration depth:	8mm
Sample table slit width (four files):	5mm, 6.35mm, 10mm, 20mm, width error ± 0.05mm
Parallel error of both sides of the sample table slit:	≤0.05mm
The probe has a neutral error:	≤0.05mm
Test speed:	1.2mm / s
Printout:	built-in thermal printer
Dimensions:	560 × 340 × 250mm
Weight:	25kg
Power:	AC220V 50Hz
