RT-405 Transport Simulation Vibration Test Table Price

RT-405 Simulate Transport Vibration Test Table

this machine is based on the United States and European transport standards and concerning the United States of similar equipment to improve manufacturing. The use of eccentric bearings in rotating elliptical trajectories is generated to simulate a car or ship’s goods during transport and the vibration of the collision. The test platform will be fixed on the eccentric bearing; when the eccentric bearing rotation, the test platform for the entire plane will produce an oval-shaped upper and lower front and rear movement, adjusting the eccentric shaft with the rotation speed equivalent to the speed of motor vehicles or vessels.

Product Details:

vibration-tester

Equipment Overview:

The RT-405 Simulate transport vibration test table is based on the United States and European transport standards and about the United States’ use of similar equipment to improve manufacturing. The use of eccentric bearings in rotating elliptical trajectories is generated to simulate a car or ship’s goods during transport and the vibration of the collision. Test platform will be fixed on the eccentric bearing, when the eccentric bearing rotation, the test platform for the entire plane would produce an oval-shaped upper and lower front and rear movement, adjust the eccentric shaft with the rotation speed is equivalent to adjust the speed of motor vehicles or vessels.



Main Features:

Digital instrument display vibration frequency; synchronous belt transmission mute, very low noise; test items using clamping rail type, easy to operate, safe; machine using heavy-duty channel steel base with anti-vibration pad, easy installation, smooth operation, without Install ground pin screw; DC motor speed control, running smoothly, load capability; rotary vibration (commonly known as Valley-type).



vibration-tester



To meet the criteria:

This instrument meets the following standards: GB / T 4857.7-92 “transport package fixed-frequency sinusoidal vibration test method.”

ISO 2247



Applications Industry:

The machine applies to toys, electronics, furniture, gifts, ceramics, packaging, and other products packaged to simulate the transport tests in line with the United States and European transport standards.

vibration-tester





Technical parameter:



Model RT-405-I RT-405-II RT-405-III
Rated load 75 kg 150 kg 230 kg
Testing dimension 120*100 cm 130*120 cm 180*150cm
Maximum Acceleration 1.25g
Frequency Frequency of 2-5 Hz continuously adjustable
Amplitude 25.4MM(1 Inch)
Power 220 V60Hz
Motor Rotary DC motor
Fence Height 33 cm,38 cm,42 cm
Dimension 120×110 cm 140×130 cm 190×160 cm
Gross 169 kg 288 kg 396 kg

vibration-tester
